Specific Gravity Frame

me：Specific Gravity Frame

Item：HZSS045-1-HZSS045-8

Details：

Used with a suitable electronic balance for specific gravity determination of fresh and hardened concrete and aggregates. A purpose built robust frame designed to support the electronic balance. The lower part of the frame incorporates a moving platform, which carries the water container allowing the test specimens to be weighted in both air and water. The balance is not included and has to selected conforming to the weighing range required. Any type of electronic balance fit with an underbench weighing facility can be used as, for example, all our models. See Balances, electronic. The frame has to be completed with the 11-D0612/A1 cradle, to hold concrete cubes or cylinders, or with the suitable Density basket for use with aggregates.

odel Forms :

Model

CAP / DIVISION

KIT  Consists of :

HZSS045-1  5000g ×0.01g   Load frame   Water tank  Mesh basket    Digital Balance with hooks

HZSS045-2  2000g ×0.01g

HZSS045-3  5000g ×0.1g

HZSS045-4  2000g ×0.1g

HZSS045-5  10000g ×0.1g

HZSS045-6 Specific Gravity Frame

HZSS045-7 pecific Gravity Water tank

HZSS045-8 Mesh basket
