2000KN Digital Concrete Compression Testing Machine

Intorduction:

The compressive testing machine is mainly used for compressive strength test of brick, stone, cement and other building materials. This tester can also be used to test the mechanical properties of other materials. This compressive test macine is also used to do flexural test.

This tester uses hydraulic loading, electronic dynamometer, so it can offer a large comression strength, 2000KN. The compressive testing machine has fuctions such as the load figures show , loading rates show , the maximum load to maintain, as well as overload protection and power features data retention .

This compressive tester also can be customized according custmers different needs and the different test materials.

Main Technical Specifications:

Max testing force :2000kN

Measurement range:4%~100%FS

Relative error of test force value:≤±1%

Upper and lower plate size:φ225mmφ300mm

Maximum distance between upper and lower plate plate:320mm

Max piston stroke (travel journey):30mm

Piston diameter:φ250mm

Hydraulic pump rated pressure:40MPa

Electric motor power :Three phase 0.75kW

Host external dimensions(mm):800×500×1200

Net Weight:About 750Kg
