Triplex HIGH-pressure Consolidometer (new Type)

Application:

The Consolidation Apparatus is used for compression test of the soil, to determine the relationship between deformation and compression of the soil, to calculate the unit settlement compression index、 resilient index as well as consolidation coefficient of the soil etc.

Specifications:

1. Load pressure:

Low pressure: 12.5kPa/800kPa/30cm2, 12.5kPa/400kPa/50cm2

Mid. Pressure: 12.5kPa/1600kPa/30cm2, 12.5kPa/800kPa/50cm2

High pressure: 4000kPa/30cm2, 2000kPa/50cm2

2. Lever ratio : 12:1, 20:1, 24:1

3. Consolidation container : 1 x beam, 2 x beams, 3 x beams

4. Area of specimen : 30cm2, 50cm2

5. Frame : Steel structure
