Digital bitumen low temperature double speed extensibility tester

Item：HZA006

Details：

Digital bitumen low temperature double velocity extensibility tester

It is test asphalt of certain shape and size placed in a water medium at a constant temperature, stretched at constant speed, and the length of the sample measured at the time of drawing is called the extension of asphalt, in centimeters. This instrument is suitable for the extended testing all kinds of asphalt, asphalt evaporation residue and modified asphalt, It is widely used in production, road construction and teaching and research departments.

:: Imported components for refrigeration systems, strong refrigeration and high stability

:: Two water cycle device to provide accuracy of test temperature

:: Import of stainless steel sink with double insulation and transparent cover

:: Water tank lighting devoice  to allow careful observation of test results

5.7 "Large LCD display, strong visual display

Stretch smooth without swing with manual locking device

:: All stainless steel countertops

1, Tensile speed: 5 ± 0.25 cm / min 1 ± 0.05 cm / min

2, Instrument specifications: 1.5 m

3, Temperature display accuracy: 0. 1 °C

4, Temperature control accuracy: ± 0.1 °C

5, Test temperature range: 0-60 °C

6, Refrigeration power: 1.3 KW

7, Heating power: 1.5 KW

8. Voltage: 220 ± 10V50HZ
