Digital Multifunction Electric Portable Compactor(Middle one hammer)

Details：

1. Heavy-duty compaction test: Weight of the hammer: 4.5KGS

Height of the fall of the hammer: 450mm

2. Light-duty compaction test: Weight of the hammer: 2.5KGS

Height of the fall of the hammer: 300mm

3. Diameter of the cylinder mould: ￠100mm and ￠152mm

4. Diameter of the hammer head: ￠50mm

5. Compaction frequency: 29 times/minute

6. Motor: 370W, 380V, 1400RPM

7. Outside size: 1340mm×450mm×610mm

8. Weight: about 148KGS

1. Heavy-duty compaction test: Weight of the hammer: 4.5KGS

Height of the fall of the hammer: 450mm

2. Light-duty compaction test: Weight of the hammer: 2.5KGS

Height of the fall of the hammer: 300mm

3. Diameter of the cylinder mould: ￠100mm and ￠152mm

4. Diameter of the hammer head: ￠50mm

5. Compaction frequency: 29 times/minute

6. Motor: 370W, 380V, 1400RPM

7. Outside size: 1340mm×450mm×610mm

8. Weight: about 148KGS

itable for the foundation fill construction design for the road, the railway, the water conservation and the building. It is used to determine the relations between the water content and the dry unit weight of the soil with the compaction method under the certain compaction function to determine the best water content and max. dry unit weight of the made ground. It is used to determine the compaction performance as per the basic of the foundation compaction control.
