Display Asphalt Mixture Marshall Compaction apparatus

Item：HZA016

Details：

This machine is the special equipment to make the specimens for the Marshall Test of the bitumen mixture.

Main technical parameter:

1. Hammer Mass : 4.536Kg±9g

2. Hammer Drop ：457mm±2MM

3. Stroke Frequency：60 ±5 Stroke Times Per Minute

4. Preset Range ：0-9999 times

5. Hammer Head Diameter：50mm

6 .Height of fall: 453.2mm±2.5mm

7. Electrical Power ： AC220VAC ／60HZ

8. Specimen size: ￠152.4±0．2mm ×95.3mm±2．5mm

9. Hammer weight： 10210g±10g

10.hammer times： 60±5times/min

11.work size : 350×440mm

12. Motor Power: 370W/1400rpm
