Strain Controlled Unconfined Compression Apparatus

Strain Controlled Unconfining Compression Test Apparatus

Application:

The Apparatus is used to test the pressure value to be borne of soft and cohesive soil specimen with bigger saturation state under the axial pressure without any limit of the sides till its damage so as to obtain unconfined compression strength.

Specifications:

1. Max. capacity: 0.6kN

2. Dimension of specimen: Ø39.1 x 80mm

3. Speed of platen rising: 2.4mm/min.

Calcareous soil unconfined pressure apparatus;Unconfined Pressure Strain Controlled Apparatus Test Equipment

Purpose: mainly used in determination of lime stable and fine grained soils (maximum particle size of no more than 5 mm) such as unconfined compressive strength of the specimens.

It is used to test the pressure value to be borne of soft and cohesive soil specimen with bigger saturation state under the axial pressure without any limit of the sides till its damage so as to obtain unconfined compression strength.

Technical parameters：

Capacity：5KN

Electric rise speed：3mm/min

The manual is rising faster：18 round/min

Screw plate52mm Screw moving distance：50mm

HZT168 JCY-1 Strain Controlled Unconfined Compression Apparatus
HZT169 HZWW-3 Electric Strain Controlled Unconfined Compression Apparatus
