Display Asphalt Flash FireTester

Item：HZA010

Details：

Flash Point Testers determine the safe mixing and application temperature values of an asphalt binder.  This instrument is designed and made as per standards GB/T3536-2008 Petroleum Products - Determination of Flash and Fire Points - Cleveland Open Cup Method and ASTM D 92 Standard Test Method for Flash and Fire Points by Cleveland Open Cup Tester. It is applicable to all petroleum products with flash points above 79℃ and below 400℃ except fuel oils.

１. Power supply: AC（220±10%）V, 50Hz.

2. Heating device: Quartz tube furnace heating, no naked fire, explosion prevented. The power is adjustable from 0W to ６00W.

3. Test flame applicator: It applies the test flame automatically.

4. Thermometer: (０～400)℃. .

5. Igniting device: (1) Ignition source: coal gas(or civil gas)

(2) Flame diameter is ０.６mm～０.8mm

6. Ambient temperature: (-10∼50)℃

7. Relative humidity: ≤85%

8. Maximum power consumption: 650W

9. Dimension: 350mm×290mm×350mm (thermometer is not included)
